High Speed Black Shell Outer Rotor Centrifugal Fan

Shandong Zhengke Industry Blower/Fan Manufacturing Co.Ltd

High Speed Black Shell Outer Rotor Centrifugal Fan

Brand Name : ZHENGKE

Model Number : ZK-300

Certification : CE, ISO9001

Place of Origin : CHINA

MOQ : 1

Payment Terms : L/C, T/T, Western Union

Supply Ability : 3000/MONTH

Delivery Time : 15-30days

Packaging Details : wooden box

Name : Outer Rotor Centrifugal Fan

Brand : Zhengke

Color : Customized

Certificate : CE, ISO9001

Model No. : ZK-300

Air Flow : 960-1450m3/h

Contact Now

Black Shell Environmental Protection High Speed External Rotor Centrifugal Fan

1. Features of outer rotor centrifugal fan

ZKW series centrifugal low noise fan (or air conditioning is a new product designed and developed by our factory in order to meet the needs d the increasingly developed air conditioning and cleaning industry. This series tan has the advantages of compact structure, convenient Installation, small vibration, low noise and light weight.ZKW series fan drive outer rotor direct drive type air inlet structure; double inlet type: power supply optional single-phase power and three-phase power supply (0.25kW-1.1kW), fan speed, single speed speed stepless speed regulation and voltage etc.. Our factory can also design and produce a variety or special types of products (such as explosion-proof fans, non-standard specilicatfons, etc.) according to the needs or users.

Main uses
1) for various air conditioning pufificatlon fresh air unit, fan cofl unit, air curtain machine and so on:
2) ventBation and heat dissipation in workshops, halls, theaters, basements, restaurants, kitchens, farms, movie xenon lamps and othar places.
I nstructlons
1) operating environment: below 1000 meters above sea level, below 40 degrees below the ambient temperature, more than 40 degrees can be customized, humidity is not greater than 80%.
2) there are four kinds of omnibearing installation bases for Installing 0or90 degrees. 180 degrees, 270 degrees, and the wiring diagrams of power supply and motor terminals.

Maners needing attention
1) the current shall not exceed the rated current of the nameplate when the fan is In operation;
2) the fan installation shall be equipped with the lack of phase and over-current protecbon device;
3) the fan turns to the tip of the tip on the volute;
4) the fan can not be opened or overloaded;
5) the fan is not allowed to extend into or out of the air inlet or air Inlet when the fan is in operation.

2. Picture of outer rotor centrifugal fan

High Speed Black Shell Outer Rotor Centrifugal Fan

3. Specification of outer rotor centrifugal fan

Model No. Dimension Power Voltage Air Flow Pressure Speed
L x W x H kW V m3/h Pa rmin
ZK-200 270 x 320 x 310 0.25 220/380 800-1500 310 1450
ZK-250 240 x 400 x 400 0.37 220/380 1000-2000 160 1450
290 x 400 x 400 0.55 220/380 2200-3000 350 1450
380 x 400 x 400 0.75 220/380 2500-4300 350 1450
ZK-280 350 x 470 x 460 1.1 220/380 3000-4500 300 1450
425 x 470 x 460 1.5 380 5000-6500 500 1450
ZK-315 500 x 350 x 520 2.2 380 5500-7500 600 1450
ZK-355 630 x 420 x 610 3 380 6000-7500 800 1450
630 x 510 x 610 4 380 9000-13500 800 1450
ZK-450 545 x 720 x 845 5.5 380 13000-17000 800 960
635 x 720 x 845 7.5 380 16000-22000 850 960
ZK-500 720 x 805 x 934 11 380 20000-30000 1000 960

4 Advantage

Shandong zhengke ventilation equipment factory, is a new technology enterprise, locating In the town of Chinese kitchen – binzhou, Shandong province, Is enterprises producing the air blower with earliest history in thia area, the company has a product design, technology development, production and testing capabilities, with fan dedicated processing equipment, improve production technology, the products sell well all over the country. The company (n 2016 won the 'Chinese famous brand* 'national authoritative testing, quality qualified products* •China's outstanding green environmental protection and energy saving products, and has passed the European system CE authentication, has the export qualification certificate. We have successfully registered the *luweida' brand and became the first China International kitchen and Wtchen expo to recommend enterprises, which is the first member of Shandong cookware association.

We have two series product: Ventilation equipment and roots blower.
Ventilation equipment: cabinet fan. centrifugal fan, 4-72 engineering, high-pressure tank fans, air-conditioning fan pressure drag cabinet, outer rotor axial flow fan. 4-82 kitchen exhaust fan. CF-11 type multi blade centrifugal fan unft. hood fan, thermal cycling fan, air conditioning fan rotor type fume purification combination, after dumping the high pressure wind cabinet, 11-62 fan, 13-4A fan. SF high pressure axial flow fan, kitchen pressure fan, motor protection cabinets and other ventilation equipment accessories such as fifteen series, fan 30 kinds of specif Nations.
Roots blower: Rotary blower, Twin lobes roots blower(dry vacuum pump, wet vacuum pump), Three lobes roots blower(dry vacuum pump, wet vacuum pump), Multi-stage centrifugal blower, Single-stage high speed centrifugal blower, Turbo blower, MVR steam compressor blower, Biogas blower, Maglev turbo blower.

We follow the 'quality-oriented, credibility first' concept of quality, adhering to the 'professional focus on the field of ventilation, to create a good environmen

High Speed Black Shell Outer Rotor Centrifugal Fan

5. FAQ

Q1. Are you direct manufacturer or trading company?

A. We are the manufacturer,we have our own factory, with 30 years manufacturing experience.

Q2. How about your warranty?

A. All of our products have a one-year quality guarantee after-sales service.

Q3. Do you accept OEM order?

A. Yes,we can produce as customers' request.

Q4. How about your factory's quality control?

A. Quality is prionrity .We always pay high attention to the quality control.

Our factory has gained CE,ISO, EAC.

Q5. What is the MOQ?

A. we accept the sample test. The MOQ is 1 unit.

Q6. How about your factory's quality control?

A. Quality is prionrity .We always pay high attention to the quality control.

Our factory has gained CE,ISO, EAC.
